Magnum Panel Fans

High capacity, extremely efficient and quiet dairy barn ventilation

  • Available in 52” and 60” panel fans.
  • Unique mounting systems for all applications.
  • Heavy duty galvanized construction.

Maximum air flow equals minimum heat stres


Magnum 52 Magnum 60
High Capacity Circulation Fan A new standard of performance



1 HP - Single Phase

  • 32,980 CFM
  • 35.6 CFM/Watt
  • 460 RPM
  • 4.7 Amps 230V





Fan Placement = Maximum of 50 ft.
Air speed ranging from 5 to 8 mph.





1 HP - 3 Phase

  • 32,870 CFM
  • 39.1 CFM/Watt
  • 460 RPM
  • 1.53 Amps 460V



1 HP - Single Phase

  • 40,000 CFM
  • 33.2 CFM/Watt
  • 430 RPM
  • 5.8 Amps 208V

1 HP - 3 Phase

  • 41,000 CFM
  • 41 CFM/Watt
  • 430 RPM
  • 1.79 Amps 460V

1 ½ HP - Single Phase

  • 51,040 CFM
  • 23.6 CFM/Watt
  • 528 RPM
  • 8.6 Amps 240V

1 ½ HP - 3 Phase

  • 51,150 CFM
  • 30.4 CFM/Watt
  • 520 RPM
  • 2.9 Amps 460V
  Fan Placement = Maximum of 60 ft.
Air speed ranging from 6 to 10 mph.

Heavy Duty Three Blade Fans Rotary Belt Tensioner
  • Galvanized frame and
    venturi panel
  • Extremely durable
  • Designed to be quiet.
  • Highly efficient.
  • Extends belt life.

Unique Mounting Options
Wood Mount Pipe Mount

Tee Clamp Mount Chain Mount
